Drainage and irrigation ditch digging equipment with adjustable depth and width. Suitable for agricultural water conservancy, orchard drainage and underground utility installation.
Product Parameters
Chain trencher parameters | ||||
No. | Item | Unit | Parameter | Note |
1 | Trench width | cm | 12-35 | |
2 | Trench depth | cm | 120 | |
3 | Matched power | HP | 50-100 | It needs to have an ultra-low speed crawling gear or be equipped with a crawling gear. When the accelerator is pressed, the speed is approximately 4-6 meters per minute. |
4 | Main structure | |||
5 | Work speed | m/min | 4-16 | |
6 | Size | mm | 4000*2300*1500 | |
7 | Weight | kg | 600 | |
8 | Application | Agricultural irrigation pipelines, pipe laying, cable laying | ||
9 | Features | Flexible operation, adjustable trench width | ||
