Precision seeding equipment that enables simultaneous seeding and fertilizing with accurate spacing and uniform depth. Suitable for corn, soybean, wheat and various crops. Effectively improves emergence rate and planting efficiency.
Product Parameters
Model | 2BF-4 |
Overall Dimension L×W×H((M) | 2.4*1.3*1.16M |
Rows | 4 lines 4 Rows |
Rowing Spacing(MM) | 260~320MM |
Matched Power(HP) | 20-50 HP |
Fertilizer Capacity | 5L |
The Form of Fertilizer Feed | Nylon Scored Pulley |
Fertiler Depth(MM) | Below the Seeds 30-70mm or the Same Depth With the Seeds |
Fertiler Colter Boot | Furrow Colter Boot |
Working Width(M) | 1.2M |
Seed Coler Boot | Moldboard Colter Boot |
Sowing Depth(MM) | 30- 5030- 50mm Below the Compacted Earth |
Linkage | Mounted Three-point Linkage |
Type of Drive | Land Wheel-Transmission |
Working Speed(KM/H) | 5-7 |
Kinds of Sowing | Corn、Soy Bean |
Weight(KG) | 430KG |
